Correa/Anayak HVM 80 CNC Travelling Column Milling Machine

Correa/Anayak HVM 80 CNC Travelling Column Milling Machine

or
Call 770-509-0744

Description

Heidenhain iTNC 530 CNC Control

2x CNC screen control, make Heidenhain, type CNC I 530

radio manual control panel - make Heidenhain, type HR-550

High Frequency Spindle - type HFS IMT Mold - max. 26,000 rpm - max. 11 kW

Floor Plates - 8,000 x 2,500 x 300 mm - T-slots 22 H12 - distance T-slots 250 mm - table load max. 15,000 kg/m²

60 Position Automatic Tool Changer

Telediagnosis system

Automatic Universal Milling Head

External Cooling - max. 5 bar

Self-Cleaning filter - tank volume 600 L

Tool Outside Air Cooling

Tool Inside Air Cooling

Hinged Belt Chip Conveyor

Protective Housing

Tool Measuring Probe M&H 20.41

Control Cabinet - ser. No. 218/14



Specifications

ManufacturerCorrea/Anayak
ModelHVM 80
Year2014
ConditionUsed
Stock Number11164
Spindle speeds6,000 rpm
High frequency spindle speed26,000 rpm
X axis travel8,000 mm
Y axis travel1,500 mm
Z axis travel2,500 mm
Floor plate dimensions8,000 x 2,500 x 300 mm
Spindle power28 kW
Total power requirement96 kW
Machine weight55 Ton
Distance Spindle Column Max1,675 mm
Feeds X/Y/Z30,000 mm/min
