Waldrich Siegen WST 1V H CNC Roll Grinding Machine
Waldrich Siegen WST 1V H CNC Roll Grinding Machine
or
Call 770-509-0744
Description
Upgraded in 2014
This roll grinding machine is located in a paper mill and used as in house service for grinding the paper machine rolls. The machine has been upgraded with Siemens software.
The machine includes a Mann+Humel filtering installation.
Specifications
| Manufacturer | Waldrich Siegen |
| Model | WST 1V H |
| Year | 1986 |
| Condition | Used |
| Stock Number | 11200 |
| Max weight of roll | 50 Ton |
| Roll length | 13,000 mm |
| Roll diameter | 2,000 mm |
| Grinding spindle speed | 450 - 1,800 rpm |
| Cutting speed | 10 - 45 m/s |
| Adjustment distance | 13,900 mm |
