Parker-Hannifin 120 Ton Twin Column Hydraulic Straightening Press
- Stock Number
- 11128
- Pressing capacity
- 120 Ton @ 3380 PSI
- Pressing Zone
- 96" Between Supports @ 100% Capacity
- Ram stroke
- 11"
- Ram diameter
- 4.5"
- Distance between columns
- 18"
- Column diameters (2)
- 3.5"
120 Ton HPM / Parker - Hannifin Twin Column Hydraulic Straightening Press
Movable fixturing that...
Details16 images
Drilco 400 Ton x 30' Traveling Head Hydraulic Straightening Press
- Stock Number
- 11127
- Pressing capacity
- 400 Ton
- Bed Length
- 360"
- Bed width
- 29.5"
POWERED HEAD TRAVERSE - CHAIN DRIVEN
"V" BLOCK SUPPORTS
POWER TURNING ROLLS
POWERED ELEVATION ...
Details7 images
6,500 Ton Hydraulic Forging Press with 80 Ton Manipulator
- Stock Number
- 11073
- Nominal force (static working pressure of 320 bar)
- 5,000 Ton
- Up-setting force (static working pressure of 420 bar)
- 6,500 Ton
- Daylight
- 4,700 mm
- Stroke of movable cross head
- 2,700 mm
- Main ram diameter (center cylinder)
- 1 set - 950 mm
- Side ram diameter (side cylinder)
- 2 sets - 750 mm
6500 Ton Open Die Free Forging Press with 80 Ton Manipulator
Four Column Push Down Oil Hydraulic...
Details5 images
Mossini PO/2M 1000 Ton Hydraulic Press
- Year
- 2002
- Stock Number
- 11072
- Pressure
- 10,000 Kn
- Table dimensions
- 1,600 x 3,000 mm
- Slide dimensions
- 1,600 x 3,000 mm
- Lower blank holder
- 600 Ton
- Blank holder stroke
- 400 mm
- Top dead center
- 1,280 mm
1000 Ton Hydraulic Press CE Mark Pressure: 10,000 Kn | Table dimensions: 1,600 x 3,000 mm | Slide dimension...
Details2 images
Siempelkamp HP 800 Isothermal Press Complex
- Year
- 2015
- Stock Number
- 11045
Fully automated, self-contained isothermal Press Complex for sale
from highly motivated seller! ...
Details3 images
Seokwang 12,000 Ton Bending Press
- Year
- 2010
- Stock Number
- 10102
- Main capacity
- 12,000 Ton
- Lifting capacity
- 120 Ton
- Ram stroke
- 1,800 mm
- Length of daylight
- 1,800 mm
- Working pressure - maximum
- 280 kg/cm²
- Descending speed
- 120 - 150 mm/second
Main capacity: 12,000 Ton | Lifting capacity: 120 Ton | Ram stroke: 1,800 mm | Length of daylight: 1,800 mm
Details11 images
ZDAS 1,600 Ton Open Die Hydraulic Forging Press with Manipulator
- Stock Number
- 10650
- Day light
- 2,800 mm
- Distance between columns
- 3,500 mm
- Stroke
- 2,000 mm
- Moving table
- 3,200 x 1,400 mm
- Speed
- 200 mm/sec
- Weight
- 250 Ton
Day light: 2,800 mm | Distance between columns: 3,500 mm | Stroke: 2,000 mm | Moving table: 3,200 x 1,400 mm
Details5 images
1500 Open Die Free Forging Press
- Stock Number
- 10462
- Press type
- Four Column Push Down Oil Hydraulic System
- Nominal force (static working pressure of 320 bar)
- 1,500 Tons
- Daylight
- 2,250 mm
- Stroke of movable cross head
- 1,500 mm
- Max working pressure
- 300 kg/cm2
- Cylinder ram diameter
- 1 Set - 800 mm
Tool Shifting Device – Stroke 4,000 mm / 157.5″ Top Die Clamping Device – 20 Ton Die Magazine Dev...
Details2 images
Duisburg 7,500 Ton Forging Press
- Stock Number
- 10228
- Retrofit
- 2008/2011
- Number of columns
- 4
- Number of cylinders
- 3
- Nominal force
- 80 MN
- Upsetting force
- 90 MN
- 1 cylinder
- 27 MN
Repair of Overall Geometry: Replacement of Column 4 Re-Machining of Columns 1-3 Machining & Pre-S...
Details5 images
Tandem Press Line Composed of (5) Five Innse Single Action with Cushion Mechanical Presses Line
- Stock Number
- 10598
- Force
- 900 ton
- Stroke
- 940 mm
- Slide regulation
- 762 mm
- Day light
- 1,778 mm
- Table size
- 4,572 x 2,464 mm
- Number of cushions
- 3
Force: 900 ton | Stroke: 940 mm | Slide regulation: 762 mm | Day light: 1,778 mm | Table size: 4,572 x 2,46...
Details6 images
4,000 Ton Hydraulic Dishing Head Press
- Stock Number
- 10242
- Movable table size
- 5,500 x 6,000 mm
- Distance between columns
- 5,900 x 4,100 mm
- Distance between table & ram
- 3,750 mm
- Pressing speed
- 100 mm/sec
- Height above floor
- 13,370 mm
- Distance below floor
- 7,500 mm
Movable table size: 5,500 x 6,000 mm | Distance between columns: 5,900 x 4,100 mm | Distance between table ...
Details2 images
30,000 Ton Closed Die Hydraulic Forging Press
- Year
- 2000
- Stock Number
- 10209
- Nominal force
- 300 MN
- Maximum stroke of movable head
- 450 mm
- Maximum distance between table & movable head
- 2,000 mm
- Distance between columns
- 2,220 mm
- Number of movable tables
- 2
- Size of movable tables
- 1,800 x 2,700 mm
Nominal force: 300 MN | Maximum stroke of movable head: 450 mm | Maximum distance between table & movable h...
Details17 images
SPS (Siempelkamp) 3500 Ton Hydroforming Press
- Year
- 2002
- Stock Number
- 10600
- Force hydroforming
- 3,500 ton
- Force deep drawing
- 1,600 Ton
- Stroke
- 1,350 mm
- Moving bolster
- 3,150 x 1,900 mm
- Cushion force
- 400 Ton
- Cushion stroke
- 450 mm
Force hydroforming: 3,500 ton | Force deep drawing: 1,600 Ton | Stroke: 1,350 mm | Moving bolster: 3,150 x ...
Details5 images
30,000 Ton 4-Column Hydraulic Forging Press
- Stock Number
- 10208
- Press force
- 30,000 Ton
- Number of cylinders
- 4
- Maximum travel of movable cross slide
- 1,250 mm
- Maximum distance between table & crosshead
- 4,650 mm
- Movable cross piece speed up/down
- 300 mm/sec
- Movable cross piece speed working
- 30 mm/sec
Four Columns Movable Cross Piece & Table Slide Top Tool Grip Devise for Hydraulic Expanding of RI...
Details4 images
Skoda 8,000 Ton 2 Column Pull Down Open Die Forging Press
- Year
- 2010
- Stock Number
- 10160
- Press power
- 8,000 Ton
- Type
- Pull-Down
- Column quantity
- 2 (Tie Rod - 4 Pos)
- Operation method
- Oil Hydraulic
- Daylight
- 6,100 mm
- Main cylinder quantity
- 3
Glama 80 Ton Manipulator 2 Columns Oilgear Hydraulics Fast Acting – Pull Down Press power: 8,000 Ton | Type:...
Details3 images
2,000 Ton Hydraulic Head Press
- Year
- 1985
- Stock Number
- 10129
- 1st stage
- 2,500 kN
- 2nd stage
- 5,000 kN
- 3rd stage
- 8,000 kN
- Rated force of hydraulic cushion
- 2,500 kN
- Travel of the cross-piece (drawing & clamping)
- 1,700 mm
- Maximum distance between table & drawing cross-piece
- 2,600 mm
1st stage: 2,500 kN | 2nd stage: 5,000 kN | 3rd stage: 8,000 kN | Rated force of hydraulic cushion: 2,500 kN
Details5 images
600 Ton Hydraulic Dishing Press
- Stock Number
- 10103
- Force
- 600 Ton
- Working pressure
- 220 kg/cm²
- Stroke - up/down
- 900 mm
- Stroke - right/left
- 1,700 mm
- Daylight
- 2,200 mm
- Bolster
- 5,500 / 1,500 mm
Force: 600 Ton | Working pressure: 220 kg/cm² | Stroke - up/down: 900 mm | Stroke - right/left: 1,700 mm
Details11 images
10,000 Ton Hydraulic Structural / Pipe Forming Bending & Cladding Press
- Stock Number
- 10924
- Pipe wall thickness range
- 10 - 63.5 mm
- Maximum length
- 12,200 mm
- Pipe diameter range
- 168 - 1,524 mm
- (6) six main cylinders bore
- 870 mm
- Stroke travel
- 1,750 mm
Pipe wall thickness range: 10 - 63.5 mm | Maximum length: 12,200 mm | Pipe diameter range: 168 - 1,524 mm
Details2 images
Siempelkamp 7000 Ton Hydraulic Press
- Year
- 2000
- Stock Number
- 10095
- Downacting ton
- 7,860 Ton
- Stroke
- 1,000 mm
- Daylight
- 2,000 mm
- Bed length
- 5,486 mm
- Ram length
- 3,581 mm
- Pressing area
- 3,480 LR x 1,981 mm
Rexroth Hydraulics – 4 Main Pumps – 200 HP – 4,700 Gallon Rolling Bolster Material Tooling Transf...
Details1 image
Seokwang 3,000 Ton Hydraulic Bending Press
- Year
- 2010
- Stock Number
- 10153
- Maximum force
- 3,000 Ton
- Daylight
- 1,500 mm
- Ram stroke
- 1,500 mm
- Table size
- 4,840 x 2,440 mm
- Main motor
- 110 kW
Maximum force: 3,000 Ton | Daylight: 1,500 mm | Ram stroke: 1,500 mm | Table size: 4,840 x 2,440 mm | Main ...
Details2 images
Bliss HS-5000 Ton Hydraulic Press
- Year
- 2014
- Stock Number
- 10393
- Capacity
- 5,000 Ton
- Distance floor to top of bed
- 457 mm
- Dimensions of bed f to b & r to l
- 2,438 x 4,343 mm
- Diameter of hole in bed
- None
- Thickness of bolster
- 330 mm
- Dimensions of bolster, f to b & r to l
- 1,460 x 3,810 mm
Size & Make of Pumps – Two Vickers PV-2125 & One Tuthill 6-0 Size & Make of Motor – Two West. 150...
Details3 images
Hasenclever SPK 2,000 Ton Screw Press
- Stock Number
- 10535
- Diameter of screw
- 400 mm
- Bed of the press (width x depth)
- 1,120 x 1,250 mm
- Ram mounting face (width x depth)
- 1,120 x 1,250 mm
- Stroke
- 450 mm
- Minimum clear height
- 1,020 mm
- Whole stroke
- 20 / min
Diameter of screw: 400 mm | Bed of the press (width x depth): 1,120 x 1,250 mm | Ram mounting face (width x...
